Dust-free bag opening machine

Equipment Introduction

   The fully automatic dust-free bag opening machine is an industrial device integrating automated bag opening, dust control and material handling. Featuring a fully enclosed structure and a dedicated dust removal system, it addresses the problems of dust pollution, low efficiency and high labor costs associated with traditional manual bag opening. The core value of this solution lies in achieving a dust-free process throughout the unpacking of powder and granular materials, while upgrading the level of production automation. It is widely applied in industries with stringent dust control requirements, including chemical, food, pharmaceutical, lithium battery, building materials and environmental protection.

二、Program Features

1、There are three models of bag opening machines, namely: blade cutting type, rotary cutting type, and drum type

2、The blade-cutting type features low speed, high emptying rate, and minimal contact between materials and packaging bags, producing nearly zero debris. It is suitable for food, pharmaceutical, and explosion-proof environments.

3、The rotary cutting type uses two or more cutting blades to open bags, with material emptied via vibration or rocking motion.

4、A vibrating screen can be optionally equipped to filter out packaging bag debris.

5、The drum type uses two or more cutting blades to open the bags, and the materials and bags simultaneously enter the drum for separation via rolling motion.

6、Front-end cleaning devices such as air shower cleaning, electrostatic dust removal and ultraviolet (UV) sterilization can be optionally equipped.

7、Optional functions such as nitrogen filling and water washing are available.

8、Optional automatic waste bag collection device is available.

三、Specifications
